IR type
Can inspect and measure the surface stress strength and strengthening depth of strengthened glass
Suitable for measuring Chemical strengthened glass and Thermal tempering glass
Single IOX glass / Double DIOX glass can be measured
Dedicated image analysis and calculation software FSM V Standard / Premium
Especially suitable for DOL>120μm
Range: Stress 0-1000Mpa Depth 10-200μm (In some cases，the upper limit is changed)
Accuracy: ±20Mpa
Light source: LED 790±10nm
Sample: Chemical tempered glass, Thermal tempered glass
Sample size: Flat over 10×10mm
OS: Windows 10
Software: FsmV Standard/Premium
Size: 280*600*220mm (head), 290*93*292mm (PC), 512*52*304 (monitor)
Weight: 14kg (head), 6kg (PC), 3kg (monitor)
